Veradius Refurbished Mobile C-arm with Flat Detector

Veradius Unity - DS

Refurbished Mobile C-arm with Flat Detector

Find similar products

When setting pedicle screws, a stent graft, or inserting a pacemaker lead, your X-ray system provides images to support confident decision making. We have re-defined teamwork during surgical imaging so you can experience a new level of efficiency in surgical procedures.

Contact us

Media Gallery

Features
The user interface is so easy, it scored in the top 10% for ease of use¹
The user interface is so easy, it scored in the top 10% for ease of use¹

The user interface is so easy, it scored in the top 10% for ease of use¹

Transform your surgical procedures with tablet-like simplicity. Operators just touch the screen on the mobile C-arm to position the shutters and iris on Last Image Hold. High level functions are clearly displayed. At each step you only see the features you need, making it easy to find the right selections.
Cut miscommunication in almost half during positioning through our patented ClearGuide²
Cut miscommunication in almost half during positioning through our patented ClearGuide²

Cut miscommunication in almost half during positioning through our patented ClearGuide²

ClearGuide and color coding on the C-arm provide a uniform reference for the operator and physician. Our user tests showed that communication about system positioning improved significantly when they used ClearGuide.¹
Reduce repositioning time by up to 42% through the Position Memory feature²
Reduce repositioning time by up to 42% through the Position Memory feature²

Reduce repositioning time by up to 42% through the Position Memory feature²

With Position Memory, you can store a previous position and recall it to speed up re-positioning. The system displays both the current position and the saved position, which guides the operator back to the exact projection required.
Increase confidence with superb image quality at excellent dose efficiency
Increase confidence with superb image quality at excellent dose efficiency

Increase confidence with superb image quality at excellent dose efficiency

To quantify the benefits of the Veradius Unity Mobile X-ray system in clinical practice, we put its novel design through a rigorous set of user tests. During the tests, 30 clinicians performed simulated procedures in a simulated OR environment. 80% of participants scored Veradius Unity as easier to use².
Easy patient access
Easy patient access

Easy patient access

The shape of the C-arc provides ample room to easily access and image normal sized and obese patients. There is plenty of space for the surgeon to work around patients. It is easy to position the C-arm, even for difficult projections.
Ease of use confirmed by user study²
Ease of use confirmed by user study²

Ease of use confirmed by user study²

Delivers consistent, undistorted edge-to-edge image quality and superb contrast resolution to support critical decisions. Take a high resolution digital exposure to check device placement. Get sharp cardiac images at 30 frames per second.
Outlining made simple (optional)
Outlining made simple (optional)

Outlining made simple (optional)

To easily mark a bifurcation or stent position on live fluoroscopy images, the Outlining tool allows you to draw on the touchscreen of the Mobile Viewing Station using a stylus pen or your finger. Press undo to correct.
Enhanced imaging for metal objects
Enhanced imaging for metal objects

Enhanced imaging for metal objects

To reduce artifacts from metal objects, such as orthopedic implants, Metal Correction can be applied during imaging. It adjusts contrast and brightness of images to enhance image quality when metal objects are present in the field of view.
Manage dose efficiently
Manage dose efficiently

Manage dose efficiently

Now it’s even easier to select relevant acquisition settings at the touchscreen on the C-arm. These are automatically applied to get the required image quality for a specific procedure and anatomy with the appropriate presets.
Superb images and low exposure
Superb images and low exposure

Superb images and low exposure

A full range of radiation dose management features such as beam filters, monoblock design for sharp pulses, and removable grid enhance excellent dose efficiency.
System uptime to meet your needs
System uptime to meet your needs

System uptime to meet your needs

Remote Services links your Philips equipment to our global Remote Services Customer Care Centers to enhance high system uptime. Services that formerly required onsite visits are now available by connecting to our remote experts, including system error identification, diagnosis, troubleshooting, and immediate remote repair online.
  • The user interface is so easy, it scored in the top 10% for ease of use¹
  • Cut miscommunication in almost half during positioning through our patented ClearGuide²
  • Reduce repositioning time by up to 42% through the Position Memory feature²
  • Increase confidence with superb image quality at excellent dose efficiency
See all features
The user interface is so easy, it scored in the top 10% for ease of use¹
The user interface is so easy, it scored in the top 10% for ease of use¹

The user interface is so easy, it scored in the top 10% for ease of use¹

Transform your surgical procedures with tablet-like simplicity. Operators just touch the screen on the mobile C-arm to position the shutters and iris on Last Image Hold. High level functions are clearly displayed. At each step you only see the features you need, making it easy to find the right selections.
Cut miscommunication in almost half during positioning through our patented ClearGuide²
Cut miscommunication in almost half during positioning through our patented ClearGuide²

Cut miscommunication in almost half during positioning through our patented ClearGuide²

ClearGuide and color coding on the C-arm provide a uniform reference for the operator and physician. Our user tests showed that communication about system positioning improved significantly when they used ClearGuide.¹
Reduce repositioning time by up to 42% through the Position Memory feature²
Reduce repositioning time by up to 42% through the Position Memory feature²

Reduce repositioning time by up to 42% through the Position Memory feature²

With Position Memory, you can store a previous position and recall it to speed up re-positioning. The system displays both the current position and the saved position, which guides the operator back to the exact projection required.
Increase confidence with superb image quality at excellent dose efficiency
Increase confidence with superb image quality at excellent dose efficiency

Increase confidence with superb image quality at excellent dose efficiency

To quantify the benefits of the Veradius Unity Mobile X-ray system in clinical practice, we put its novel design through a rigorous set of user tests. During the tests, 30 clinicians performed simulated procedures in a simulated OR environment. 80% of participants scored Veradius Unity as easier to use².
Easy patient access
Easy patient access

Easy patient access

The shape of the C-arc provides ample room to easily access and image normal sized and obese patients. There is plenty of space for the surgeon to work around patients. It is easy to position the C-arm, even for difficult projections.
Ease of use confirmed by user study²
Ease of use confirmed by user study²

Ease of use confirmed by user study²

Delivers consistent, undistorted edge-to-edge image quality and superb contrast resolution to support critical decisions. Take a high resolution digital exposure to check device placement. Get sharp cardiac images at 30 frames per second.
Outlining made simple (optional)
Outlining made simple (optional)

Outlining made simple (optional)

To easily mark a bifurcation or stent position on live fluoroscopy images, the Outlining tool allows you to draw on the touchscreen of the Mobile Viewing Station using a stylus pen or your finger. Press undo to correct.
Enhanced imaging for metal objects
Enhanced imaging for metal objects

Enhanced imaging for metal objects

To reduce artifacts from metal objects, such as orthopedic implants, Metal Correction can be applied during imaging. It adjusts contrast and brightness of images to enhance image quality when metal objects are present in the field of view.
Manage dose efficiently
Manage dose efficiently

Manage dose efficiently

Now it’s even easier to select relevant acquisition settings at the touchscreen on the C-arm. These are automatically applied to get the required image quality for a specific procedure and anatomy with the appropriate presets.
Superb images and low exposure
Superb images and low exposure

Superb images and low exposure

A full range of radiation dose management features such as beam filters, monoblock design for sharp pulses, and removable grid enhance excellent dose efficiency.
System uptime to meet your needs
System uptime to meet your needs

System uptime to meet your needs

Remote Services links your Philips equipment to our global Remote Services Customer Care Centers to enhance high system uptime. Services that formerly required onsite visits are now available by connecting to our remote experts, including system error identification, diagnosis, troubleshooting, and immediate remote repair online.

Specifications

X-ray generation
X-ray generation
X-ray generator
  • Monoblock 80 KHz high frequency generator
Maximum generator output
  • 15 kW
X-ray tube
  • Rotating Anode (tube)
Connectivity
Connectivity
WLAN
  • optional
Geometry
Geometry
C-arc depth
  • 73 cm/ 29 inch
Lowest lateral position
  • 102.7 cm/ 40.4 inch
Source Image Distance
  • 99.3 cm/ 39 inch
Angulation
  • + 90 / - 50 °
C-arc
  • Color coded, fully balanced
Flat detector
Flat detector
Pixel pitch
  • 184 µm
Detector Area
  • 26.2 cm/ 10.3 inch x 26.2 cm/ 10.3 inch
Matrix size
  • 1560x1420 pixels
Flat detector
  • Trixell amorphous silicon detector
X-ray generation
X-ray generation
X-ray generator
  • Monoblock 80 KHz high frequency generator
Maximum generator output
  • 15 kW
Connectivity
Connectivity
WLAN
  • optional
See all specifications
X-ray generation
X-ray generation
X-ray generator
  • Monoblock 80 KHz high frequency generator
Maximum generator output
  • 15 kW
X-ray tube
  • Rotating Anode (tube)
Connectivity
Connectivity
WLAN
  • optional
Geometry
Geometry
C-arc depth
  • 73 cm/ 29 inch
Lowest lateral position
  • 102.7 cm/ 40.4 inch
Source Image Distance
  • 99.3 cm/ 39 inch
Angulation
  • + 90 / - 50 °
C-arc
  • Color coded, fully balanced
Flat detector
Flat detector
Pixel pitch
  • 184 µm
Detector Area
  • 26.2 cm/ 10.3 inch x 26.2 cm/ 10.3 inch
Matrix size
  • 1560x1420 pixels
Flat detector
  • Trixell amorphous silicon detector

Documentation

Brochure (2)

Brochure

Brochure (2)

Brochure

See all documentation

Brochure (2)

Brochure

  • ¹ Referring to Sauro’s study results: Top 10% for ease of use is based on an average score of 83.5 on the System Usability Scale (SUS) by 15 users in an independent study, interacting with the C-arm software’s user interface. The SUS was developed by J.Sauro (See “A Practical Guide to the System Usability Scale: background, Benchmarks, & Best Practices, “by J. Sauro, 2011, Denver, CO, USA, Measuring Usability LLC.) Sauro’s study tested the ease of use of 500 consumer and commercial products and did not necessarily include mobile surgery C-arms.
  • ² Referring to the UseLab GmbH user test: Results obtained during user tests performed in November 2013 by Use-Lab GmbH, an independent company. The tests involved 30 USA based clinicians (15 physicians teamed up with 15 nurses or X-ray technicians), who performed simulated procedures in a simulated OR environment. None of them had worked with a Philips C-arm or with each other before.
